Welcome to the HBSI Forums Image Gallery.

Towfish Constructio­n
21 items
Show off your DIY Towfish Images.  Please give us some specs on construction materials, measurements, etc.

Down Imaging Picts
80 items
Picts of Humminbirds New "Down Imaging" Sonar

Installatio­n Photos
111 items
Please post your images or video of your transducer or Unit installtion.  Please put a description of the boat make and model as well as the type transducer and Unit model.

Shipwrecks and Sunken Boats
141 items
Upload snapshots and images of interesting Wrecks and sunken boats.

Salt Water Images
45 items
Post your salt water images and snapshots.

Salt Water Deep Wrecks 75'+
12 items
Post your interesting images of deep wrecks in salt water.

Mapping and Charts
2 items
Post images and snapshots of mapping and chart views.

Software Screenshots
45 items
Post images and screenshots from waypoint, charting, and side imaging software.

Bridges, Pilings, Docks, and Boat Ramps
42 items
Post your snapshots of Bridges, Boats, Pilings, Etc.

Brush Piles, Grass, and Vegetation
6 items
Post your images of brush piles, vegetation, etc.

Deep Water 75'+
5 items
Post your images of Deep Water wrecks, fish or structure.

Trees, Stumps, Logs
37 items
Post your Side Imaging snapshots of interesting Trees, Stumps, or Logs

Fish Images
92 items
Upload images and snapshots of fish, baitballs and other fish related images.

Search and Recovery Images
9 items
Post your interesting images of Search and Recovery, sunken cars, boats, etc.  Please be respectfull if posting images of bodies.  No names or references that may identify the deceased please.

Documents
8 items, and 24 in sub-albums
Wiring Diagrams (11), 997 Removeable Sunshade (10), Understanding Side Imaging (3)

User Albums
21 items in sub-albums
Gary Still, Brian's SI Screenshots (15), Winter 2009 - 2010 (6)

Recent Items

Items view: Normal view Filestack view
Sort by: ID Date Title Views Rating | Sort Order: Ascending Descending

Stumps, logs & weed edge
SI Settings:
Freq: 455Khz
Sensitivity: Auto
Contrast: 13
Sharpness: Low
Speed and depth shown on shapshoot
 Views: 1024
Posted by blharr4400
Mar 27, 2010
in Trees, Stumps, Logs

Stump and weed edge
SI Settings:
Freq: 455Khz
Sensitivity: Auto
Contrast: 13
Sharpness: Low
Speed and depth shown on shapshoot
 Views: 1012
Posted by blharr4400
Mar 27, 2010
in Trees, Stumps, Logs

Single Stump # 1
SI Settings:
Freq: 455Khz
Sensitivity: Auto
Contrast: 13
Sharpness: Low
Speed and depth shown on shapshoot
 Views: 982
Posted by blharr4400
Mar 27, 2010
in Trees, Stumps, Logs

All kinds of goodies
Far left white specs are reeds in 2-4 feet of water
next on the left side would be a coontail bed on the drop off
left/right is the bottom of the drop off with a "low growing" vegitation (only a foot or so tall)
far right is the bottom of the drop off that transitions into a flat with some holes on…
 Views: 2417
Posted by blharr4400
Mar 27, 2010
in Brush Piles, Grass, and Vegetation

Canoe / kayak
Found 100 feet infront of boat launch and I believe it to be a canoe / kayak.

SI Settings:
Sensitivty: Auto
Contrast: 14
Sharpness: Low
Range: 125 right side
Speed and depth on snap shoot
 Views: 661
Posted by blharr4400
Mar 27, 2010
in Shipwrecks and Sunken Boats

Bait Fish
Large school of bait fish possibly a school of bluegills/crappie

SI Settings
Sensitivity: Auto
Contrast: 14
Sharpness: Low
Range: 125 feet both sides
Speed and depth shown in shap shoot
 Views: 1406
Posted by blharr4400
Mar 26, 2010
in Fish Images

Suspened fish
I ran across these while scanning the lake the other day.  I am in southwest michigan and the largest species I know of in this lake is large mouth bass and northern pike.  I would guess by the number of fish this that this is a school of large mouth bass as I did not stop and fish the school.  It a…
 Views: 2445
Posted by blharr4400
Mar 26, 2010
in Fish Images

Free boat!!!
first treasure I found with my new 1197C si...  Everyone always said fishe the "rock pile" 300 yards off the boat ramp and that is the size of a john boat.  Looked for it many times with 2D sonar and never found it.  Now the SI shows me the "rock pile" really is a john boat.  Thank Humminbird!!!
 Views: 848
Posted by blharr4400
Mar 23, 2010
in Shipwrecks and Sunken Boats

#6 starboard stern sanded
 Views: 1117
Posted by Jolly Roger
Mar 22, 2010
in Winter 2009 - 2010

#4 portside completely sanded downP3200006kopie
 Views: 1047
Posted by Jolly Roger
Mar 22, 2010
in Winter 2009 - 2010

#3 portside
Half sanded, half scratched.......
 Views: 1043
Posted by Jolly Roger
Mar 22, 2010
in Winter 2009 - 2010

#5 Starboard stern scratchedP3150120kopie
 Views: 1047
Posted by Jolly Roger
Mar 22, 2010
in Winter 2009 - 2010

#1 Starboard bow
That's how the bow looked after it was pressure hosed in fall last year.
The old paint got partly washed away. Note the colour difference above and under the waterline: Everything under the waterline was "easy" to romove, because the water washed the antfouling off during the years and the thickness…
 Views: 1029
Posted by Jolly Roger
Mar 22, 2010
in Winter 2009 - 2010

#2 mid ship P2270104
This isn't the moon's surface. It's the midship under water part  :o
 Views: 1029
Posted by Jolly Roger
Mar 22, 2010
in Winter 2009 - 2010

SI on SternMate™ 2
View from port. Hummingbird SI transducer is mounted on a SternMate™ transducer mounting system. The system is installed using a proprietary high speed adhesive without the necessity of damaging screw holes. The boat is our 16DLX Carolina Skiff.  Boaters worldwide are now mounting their transom-moun…
 Views: 2231
Posted by Captn_C
Mar 20, 2010
in Installatio­n Photos
